Multi Cell Innerduct

Installation methods include open cut trench pull or chute plowing directional.

Multi cell innerduct.

Maxcell is a versatile solution for the complex problems. Multicell can be made with standard wall heavy wall and bullet resistant fiberglass as well as steel and pvc. Today s network owners and builders use maxcell to increase their cable density by as much as 300. New construction applications have yielded installation of up to 300 more cabling per conduit over rigid ducts.

3 cell white grey orange 4 cell white grey orange green multi gard fixed bends use the same coupling design as straight sections all bends are provided with. Specifically designed for use in outdoor direct bury and concrete encased applications it is manufactured in 20 foot lengths for easy handling and installation. Maxcell is the only flexible fabric innerduct system designed specifically for the network construction industry. Multi gard multi cell raceway systems pvc 1 800 322 7566 3 wt.

Preinstalled pull tapes are also optional. The unique fabric construction allows maxcell to conform to the shape of cables placed within greatly reducing the wasted space associated with rigid innerduct. Innerduct multiple lengths in sizes usually 1 1 4 and smaller pulled parallel into a larger conduit to divide it into multiple conduits. Vikimatic custom configures multi cell to your specifications.

Up to 3 packs can be placed in a 4 conduit. The device is made of polyethylene and is available in single two or three cell configurations. The two and three cell versions include shared wall features. Multi gard pvc duct is a multi celled cable management and protection raceway system.

Color coded pull tapes are pre installed. Optiduct multicell innerduct allows installation of up to six fiber optic cables in a 4 inch pvc duct. In occupied conduits maxcell s design has allowed for easy pathway creation when overriding existing cabling or. Direct buried burying one or more conduit lengths directly in the ground as pathways for future cable installation.

Standard thread color is black and the cells are orange. The 3 3 cell product is designed to hold cables up to 1 05 in diameter in each cell. The unique textile construction allows maxcell to conform to the shape of cables placed within greatly reducing the wasted space associated with rigid innerduct. 3 3 cell maxcell edge is designed for use in 3 or larger conduits.

Maxcell edge fabric innerduct is designed to maximize the capacity of conduits in network infrastructure while preserving space for future network deployments. Standard multi gard supplied with grey and one white tracer innerduct add c for multi colored innerducts.
